Rotary drilling tools drilling bucket Core Barrel with Bullet teeth

Name: Rotary drilling tools drilling bucket Core Barrel with Bullet teeth
Brand: TUFF
Price: 1 USD

Quality Rotary drilling tools drilling bucket Core Barrel with Bullet teeth for sale

Brand Name : TUFF

Model Number : 600-3000mm or as required

Certification : ISO9001

Place of Origin : China

MOQ : 1 Piece

Price : $1,000.00 - $10,000.00/Unit

Payment Terms : L/C, D/A, D/P, T/T

Supply Ability : 200 Unit/Units per Month

Delivery Time : 3-5 days after payment

Packaging Details : Drilling core barrel packaged with plastic cases

Material : 16mn-Q355B

Kelly Box : Sany--150 ,Bauer--200 ,Bauer--250

Teeth Type : Bullet teeth

Color : Black or as required

Contact Now

Rotary drilling tools drilling bucket Core Barrel with Bullet teeth

Feature:
Cutting ring with rock drilling bits and releases the internal stress of rock；
Rock drilling bits perform stage breaking and drilling ;
Small barrel facilitates the coring operation; large barrel performs stage breaking;
Applicable layers: backfill layer,medium weathered rock, bedrock；

Rotary drilling tools drilling bucket Core Barrel with Bullet teeth

Products Show:

Cutting Dia.	Shell HIT.	Shell OD.	Shell THK.	Stiffening Ring THK.	Stiffening Ring HIT.	Teeth No.	Weight
φ600	1200	520	16	20	200	6	520
φ800	1200	720	16	20	200	9	672
φ900	1200	820	16	20	200	10	750
φ1000	1200	920	16	20	200	11	847
φ1200	1200	1120	16	20	200	13	1010
φ1500	1200	1420	16	20	200	16	1370
φ1600	1200	1520	16	20	200	17	1493
φ1800	1000	1720	20	20	200	19	1841
φ2000	800	1920	20	20	200	21	1852
φ2200	800	2120	20	20	200	23	2329
φ2500	800	2420	20	20	200	27	2705
φ2800	800	2720	20	20	200	30	3200
φ3000	800	2920	20	20	200	32	3800
Remark:all measurements in millimeters (mm); weight in kilograms(kg);

Customizable Items:
Cutting DIA. Custom : design various cutting diameter based on demand, like φ950,φ1050 etc.
Shell HIT. Custom : design as demand, prolong or shortten, increase of efficiency by drilling more.
Key Component Reinforce Custom : strengthen the key component to extend life cycle;
Kelly Box Custom : custom kelly box size based on the kelly bar, like 130*130, 150*150,200*200 etc;
Teeth No. Custom : encrypt the drilling teeth based on demand etc;

Rotary drilling tools drilling bucket Core Barrel with Bullet teeth

Rotary drilling tools drilling bucket Core Barrel with Bullet teeth Images
